Dimlux Xplores Series 730W 9X LED 3.0

Categories: , , ,
SKU: In stock

The Dimlux Xplore 730W 9X is specially made to fit in a grow tent. You get the same specifications as the Xplore 730W, but extra compact!

Our specifications are guaranteed!

The Dimlux Xplore 730W 3.0 is officially DLC HORT Listed, meaning it’s tested and verified for performance, reliability, and efficiency by the DesignLights Consortium®, an independent organization ensuring trusted lighting quality standards. So it’s especially designed for growers who want real results and guaranteed efficiency!

High quality budget friendly!

Since its introduction, the dimlux xplore series has stood for high-end led performance at an accessible price. With the updated dimlux xplore 2.7 umol, that promise goes even further — thanks to a series of powerful upgrades that improve efficiency, durability, and light control.

The fixture now features a virtually unbreakable lens with integrated light benders. This innovative lens is built to last, making the fixture even more durable, while also minimizing light loss to the walls and directing more light where it matters: onto your plants. In addition, the asymmetrically placed led diodes ensure more light reaches the edges of your grow area, promoting even growth across the entire canopy. With a system efficiency of 2.7 µmol/j, an integrated driver, and proven reliability, the xplore 2.7 delivers exceptional performance with minimal energy use. Just like its predecessor, it’s robust, easy to install, and upgradeable with optional uv-a and far-red modules.



What’s new?
  • System efficiency 3.0 μmol/J
  • unbreakable lens with light benders
  • ip68 quick lock power connector
  • integrated led driver
  • 5-year warranty

Product Features:

The Dimlux Xplore Series 730W and 730W 9X LED offer an unprecedented price / performance ratio featuring a perfect blend of both full-spectrum white LED diodes and red LED diodes. This results in the perfect spectrum for all phases of growth. The mix of white and red LEDs result in a relatively high ratio of bluish light. Blue light keeps your crop tight and compact in the vegetative stage and adds to optimal morphogenesis and light uptake by the plant. The red part is ideal for flower and is accountable for the high yield. The Xplore 730W integrated LED driver is fully built into the fixture and can dim the LED fixture by the Maxi Controller or with the onboard dim button. A 290W, 430W, 580W or 730W setting may be selected to give maximum light output. Lightweight and easy to install, if hung by means of Rope Ratchets the height of the fixture can be adjusted as your plants grow. This high-performing, high-efficiency LED 6 Bar Fixture can be used singly or as part of a lighting array.

thanks to improved top-class dimlux leds in combination with a powerful integrated driver, system efficiency is pushed to new heights of up to 3.0 µmol/j — setting a new benchmark in its category. Light output is boosted to an impressive 2197 µmol/s, delivering more usable light with less energy.

thanks to the asymmetrically placed led diodes, the xplore series delivers up to 80% more light at the edges of your grow area. This ensures more even light distribution, improved growth uniformity, and reduces over-saturation in the center — resulting in a healthier canopy and higher yields. It’s this smart optical design that sets dimlux apart from the competition.

with unique light benders the virtually unbreakable lens is built for durability and easy maintenance. Its integrated light benders efficiently redirect light toward the crop, minimizing light waste and maximizing penetration for optimal performance over time.

Product Specifications:

  • Light Source LED 730W
  • Light Output (PPF) 2160 μmol/s
  • Light Output Total (PPF 350-800nm) 2197 μmol/s
  • PAR Photon Efficacy (400-700nm) 3.0 μmol/J @ 230-240V AC
  • Total Photon Efficacy (350-800nm) 3.02 μmol/J @ 230-240V AC
  • AC Input Power 730W @ 230-240V AC
  • AC Input Voltage 200-277V AC, 50/60Hz
  • Driver 730W Integrated High Voltage LED Driver
  • Spectrum Full Spectrum White and Red LED Diodes
  • Beam Angle 110°
  • Optics High Transmittance Lens With Light Benders
  • LED Position Asymmetrical
  • Recommended Mounting Height 150x150cm, min. 40cm / 4.9×4.9′, min. 1.3′
  • Max. Ambient Temperature -25 ~ 40°C / -13 ~ 104°F
  • Control By Dim Button or MaxiController
  • Total Harmonic Distortion (THD) < 10%
  • Lifetime L90 > 50,000h
  • IP Rating IP44
  • Certifications CE, DLC Listed, UKCA, CASA, ETL
  • Warranty 5 Year Standard
  • Measurements 900×990×38mm / 35.43×38.98×1.50 inch
  • Weight 6.2kg / 13.67 lbs
