Discover the Future of Horticulture with DimLux Xtreme Series LED
Enter a new era of horticultural lighting with the DimLux Xtreme Series LED, the latest breakthrough from DimLux. Twelve years after launching the world’s first adjustable HPS ballast with Maxi Controller, DimLux is once again setting the standard with this revolutionary LED solution.
Revolutionary LED Technology
This groundbreaking LED fixture, born from 12 years of experience and expertise in lighting technology, heralds a new era in horticultural lighting. The DimLux Xtreme Series LED merges patented technologies and the latest LED innovations in an optimal thermal design. For professional growers, this promises not only a superior growing experience but also a significant return on investment.
Unique PhytoVegSpec® Spectrum
Experience complete control with our unique, adjustable PhytoVegSpec® growing spectrum. This ensures even distribution and deep penetration of light, resulting in consistently high-quality crops and yields.
High PPFD Levels and Flexibility
The DimLux Xtreme Series LED generates exceptionally high PPFD levels across a 1.5—1.5 m area, with a full growth spectrum. The fixtures are dimmable without efficiency loss and programmable for various times of the day and growth stages.
RGB LEDs
An innovative addition is the RGB LEDs. These serve not only as supplementary light but also as green work light during the night phase, automatically activated by a built-in motion sensor.
DimLux Xtreme Series LED -NIR
As the icing on the cake, DimLux introduces the Xtreme Series LED – NIR. This variant integrates near-infrared (NIR) light for enhanced plant growth and more effective photosynthesis. Ideal for growers aiming to optimise the growth and development of their crops.
Specification
|
Light Source |
LED 500W |
|
|
|
|
Spectrum Adjustable PhytoVegSpec® Indoor +NIR |
|
|
Light Output (PPF) |
1420 μmol/s |
|
Light Output Total (PPF 350-800nm) |
1550 μmol/s |
|
PAR Photon Efficacy (400-700nm) |
2.67 μmol/J @ 230-240V AC |
|
Total Photon Efficacy (350-800nm) |
2.87 μmol/J @ 230-240V AC |
|
AC Input Power |
540W @ 230-240V AC |
|
AC Input Voltage |
120-277V AC, 50/60Hz |
|
Beam Angle |
90° — 120° |
|
Optics |
Patented Deep Penetration Ultra High Transmittance Lens |
|
Auxiliary Light |
Patented Light Pipe Multi Color 65k |
|
Proximity sensor |
Doppler Radar |
|
Mounting Height Above Canopy |
20-50cm / 7.8-19.7 in |
|
Thermal Management |
Passive |
|
Max. Ambient Temperature |
40°C / 105°F |
|
Control |
By Maxi Controller or Internal Controller |
|
Smartports (3x) |
Interlink, Plant Temperature Sensor, Light Sensor |
|
Display For Spectrum and GUI |
1.54″ 65k Color IPS |
|
Total Harmonic Distortion (THD) |
< 10% |
|
Lifetime L90 |
> 50,000h |
|
IP Rating |
IP65 |
|
Certifications |
CE, UL 8800, UL 1598 Wet Location, DLC |
|
Warranty |
5 Year Standard |
|
Measurements |
833x810x57mm |
|
|
32.8×31.9×2.2 inch |
|
Weight |
13,3kg / 29.32 lbs |
